Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV

Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV

    • Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV
    • Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV
    • Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV
    • Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV
    • Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV
  • Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV

    Product Details:

    Place of Origin: China
    Brand Name: SDLIFT
    Certification: CE ISO9001 SGS BV
    Model Number: SJY0.3-12

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: USD1980 - 5800 / Set
    Packaging Details: Iron case or plywood case package
    Delivery Time: 5-20 work days after deposit
    Supply Ability: 3800 units per year
    Contact Now
    Detailed Product Description
    Item: China Factory Supply Hydraulic Mobile Lift Small Electric Scissor Lift Warranty: 24 Months
    Lifting Heightcontrol: 4m - 20m Lifting Heightcontrol System: Electric Or Hand Pump
    Material: High Strength Mn Steel Tube Q345 Safety Device: Explosion Proof Lock Valve, Emergency
    Motor Power: From Italy Or Chinese Famous Brand Load Capacity: 300kg 500kg 1000kg
    Color: Blue Orange Or Customized

    China Factory Supply Hydraulic Mobile Lift Small Electric Scissor Lift

    With 24 Months Warranty:



    Product Description:

    The China Factory Supply Hydraulic Mobile Lift Small Electric Scissor Lift is mainly used to lift workers to high place for repairs, maintenance, cleaning or installation and so on. You can move it easily to the right working area.

    The Mobile Scissor Lift can be also equipped with battery. With the battery, you don’t need to connect AC power, and you can let the mobile scissor lift at some work areas without power.

    Also, the mobile scissor lift can be installed with the driven wheel to move it by hands without any hardness.



    Product feature:
    1. The mobile scissor lift is mainly used to lift workers to high place for repairs, maintenance, cleaning or installation ect.
    2. An ideal equipment of safety operation.
    3. It is characterized by great loading capacity, can be designed as your request.
    4. Move convenient, work easy and raise & fall stable.
    5. Local voltage can be customized.(110v,220v.380v,415v)
    6. Lift power: AC,DC or diesel available



    Safety device:
    1. Sensitive overload protection device and locking device for falling down
    2. Explosion–proof valve: prevent the hydro oil pipe from cracking.
    3. Overflow valve: it will prevent the pressure too high when the machine rises up.
    4. Hand decline valve: it can let the machine falls down when power is off.
    5. Safety lock: the lift machine can’t work if your operation is wrong.



    Product list:



    Model

    Capacity

    Table size

    Max height

    Work height

    Total dimension

    Net weight

    SJY0.3-4

    300Kgs

    1500×750mm

    4m

    5.7m

    1850×900×1900mm

    400Kgs

    SJY0.3-6

    300Kgs

    1500×750mm

    6m

    7.7m

    1850×900×1970mm

    650Kgs

    SJY0.3-8

    300Kgs

    1650×1000mm

    8m

    9.7m

    2100×1200×2460mm

    1200Kgs

    SJY0.5-8

    500Kgs

    1980×1220mm

    8m

    9.7m

    2500×1550×2380mm

    1400Kgs

    SJY0.8-8

    800Kgs

    2000×1220mm

    8m

    9.7m

    2600×1550×2640mm

    1700Kgs

    SJY0.3-10

    300Kgs

    2100×1220mm

    10m

    11.7m

    2700×1550×2380mm

    1500Kgs

    SJY0.5-10

    500Kgs

    2100×1220mm

    10m

    11.7m

    2700×1550×2380mm

    1600Kgs

    SJY1.0-10

    1000Kgs

    2220×1220mm

    10m

    11.7m

    2820×1720×2850mm

    2380Kgs

    SIY0.3-12

    300Kgs

    2550×1500mm

    12m

    13.7m

    3150×1860×2850mm

    2580Kgs

    SIY0.5-12

    500Kgs

    2550×1500mm

    12m

    13.7m

    3150×1860×2850mm

    2780Kgs

    SJY1.0-12

    1000Kgs

    2600×1500mm

    12m

    13.7m

    3200×2015×3090mm

    3580Kgs

    SJY0.3-14

    300Kgs

    2990×1600mm

    14m

    15.7m

    3600×2000×2850mm

    3000Kgs

    SJY0.5-14

    500Kgs

    2990×1600mm

    14m

    15.7m

    3600×2000×2850mm

    3200Kgs

    SJY0.3-16

    300Kgs

    3230×1600mm

    16m

    17.7m

    3700×2000×3030mm

    3900Kgs

    SJY0.3-18

    300Kgs

    3230×1600mm

    18m

    19.7m

    3700×2000×3250mm

    4500Kgs

    SJY0.3-20

    300Kgs

    3230×1600mm

    20m

    21.7m

    3700×2000×3450mm

     5100Kgs





    The workshops:





    Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BVHydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BVHydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BVHydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV



    Our Services
    1) We can design the mobile scissor lift as per your requirement.
    2) The mobile scissor lift will be recommended to you once we got your requirement.
    3) Shipment can be arranged from our port to your destination port.
    4) Operation video can be sent to you if needed.
    5) User-friendly English manual for machine installation using and maintenance.
    6) 2 years warranty for whole machine without man-made faults.
    7) We will send you parts for free if there are any non-human factors faults during warranty time.
    8) Supply 24-hours technical assistance by email, telephone or other communication online.
    9) Engineers are available to your country if necessary.
