Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV

China Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV supplier
Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV supplier Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV supplier Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV supplier Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV supplier Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV supplier

Large Image :  Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV

Product Details:

Place of Origin: China
Brand Name: SDLIFT
Certification: CE ISO9001 SGS BV
Model Number: SJY0.3-12

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: USD1980 - 5800 / Set
Packaging Details: Iron case or plywood case package
Delivery Time: 5-20 work days after deposit
Supply Ability: 3800 units per year
Contact Now
Detailed Product Description
Item: China Factory Supply Hydraulic Mobile Lift Small Electric Scissor Lift Warranty: 24 Months
Lifting Heightcontrol: 4m - 20m Lifting Heightcontrol System: Electric Or Hand Pump
Material: High Strength Mn Steel Tube Q345 Safety Device: Explosion Proof Lock Valve, Emergency
Motor Power: From Italy Or Chinese Famous Brand Load Capacity: 300kg 500kg 1000kg
Color: Blue Orange Or Customized

China Factory Supply Hydraulic Mobile Lift Small Electric Scissor Lift

With 24 Months Warranty:



Product Description:

The China Factory Supply Hydraulic Mobile Lift Small Electric Scissor Lift is mainly used to lift workers to high place for repairs, maintenance, cleaning or installation and so on. You can move it easily to the right working area.

The Mobile Scissor Lift can be also equipped with battery. With the battery, you don’t need to connect AC power, and you can let the mobile scissor lift at some work areas without power.

Also, the mobile scissor lift can be installed with the driven wheel to move it by hands without any hardness.



Product feature:
1. The mobile scissor lift is mainly used to lift workers to high place for repairs, maintenance, cleaning or installation ect.
2. An ideal equipment of safety operation.
3. It is characterized by great loading capacity, can be designed as your request.
4. Move convenient, work easy and raise & fall stable.
5. Local voltage can be customized.(110v,220v.380v,415v)
6. Lift power: AC,DC or diesel available



Safety device:
1. Sensitive overload protection device and locking device for falling down
2. Explosion–proof valve: prevent the hydro oil pipe from cracking.
3. Overflow valve: it will prevent the pressure too high when the machine rises up.
4. Hand decline valve: it can let the machine falls down when power is off.
5. Safety lock: the lift machine can’t work if your operation is wrong.



Product list:



Model

Capacity

Table size

Max height

Work height

Total dimension

Net weight

SJY0.3-4

300Kgs

1500×750mm

4m

5.7m

1850×900×1900mm

400Kgs

SJY0.3-6

300Kgs

1500×750mm

6m

7.7m

1850×900×1970mm

650Kgs

SJY0.3-8

300Kgs

1650×1000mm

8m

9.7m

2100×1200×2460mm

1200Kgs

SJY0.5-8

500Kgs

1980×1220mm

8m

9.7m

2500×1550×2380mm

1400Kgs

SJY0.8-8

800Kgs

2000×1220mm

8m

9.7m

2600×1550×2640mm

1700Kgs

SJY0.3-10

300Kgs

2100×1220mm

10m

11.7m

2700×1550×2380mm

1500Kgs

SJY0.5-10

500Kgs

2100×1220mm

10m

11.7m

2700×1550×2380mm

1600Kgs

SJY1.0-10

1000Kgs

2220×1220mm

10m

11.7m

2820×1720×2850mm

2380Kgs

SIY0.3-12

300Kgs

2550×1500mm

12m

13.7m

3150×1860×2850mm

2580Kgs

SIY0.5-12

500Kgs

2550×1500mm

12m

13.7m

3150×1860×2850mm

2780Kgs

SJY1.0-12

1000Kgs

2600×1500mm

12m

13.7m

3200×2015×3090mm

3580Kgs

SJY0.3-14

300Kgs

2990×1600mm

14m

15.7m

3600×2000×2850mm

3000Kgs

SJY0.5-14

500Kgs

2990×1600mm

14m

15.7m

3600×2000×2850mm

3200Kgs

SJY0.3-16

300Kgs

3230×1600mm

16m

17.7m

3700×2000×3030mm

3900Kgs

SJY0.3-18

300Kgs

3230×1600mm

18m

19.7m

3700×2000×3250mm

4500Kgs

SJY0.3-20

300Kgs

3230×1600mm

20m

21.7m

3700×2000×3450mm

 5100Kgs





The workshops:





Hydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BVHydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BVHydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BVHydraulic Mobile Platform Lift Small Electric Scissor Lift SGS BV



Our Services
1) We can design the mobile scissor lift as per your requirement.
2) The mobile scissor lift will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 years warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) Engineers are available to your country if necessary.
