6m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work
6m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work
6m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work
6m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work
6m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work

6m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work

Product Details

Place of Origin: China

Brand Name: SDLIFT

Certification: CE ISO9001 SGS BV

Model Number: GTJZ06

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: USD8980 - 12800 / Set

Packaging Details: Iron case or plywood case package

Delivery Time: 5-20 work days after deposit

Supply Ability: 1200 units per year

Get Best Price

Product Details

Product Description
Highlight:

aerial lift scaffolding

,

mobile elevated work platform

Application:
Hydraulic Platform Mobile Scissor Lift Self Propelled Sky Lift
Guardrail:
Foldable
Usage:
Scissor Lift Self Propelled
Wheels:
90 Degree Turnable
Protection:
Potholes Protection
Warning Light:
Working Light
Extend Platform:
900mm
Grade Ability:
25%
Max. Drive Speed:
3.2m Km/h (platform Stowed)
Certification:
CE ISO
Application:
Hydraulic Platform Mobile Scissor Lift Self Propelled Sky Lift
Guardrail:
Foldable
Usage:
Scissor Lift Self Propelled
Wheels:
90 Degree Turnable
Protection:
Potholes Protection
Warning Light:
Working Light
Extend Platform:
900mm
Grade Ability:
25%
Max. Drive Speed:
3.2m Km/h (platform Stowed)
Certification:
CE ISO
6m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work

Hydraulic Platform Mobile Scissor Lift Self Propelled Sky Lift Platform​



Application:



Self Propelled Sky Lift Platform is ideal lift platform for aerial maintain and clean, used indoor or outdoor. With AC driven system. Electric lift makes low noise and no emission when working. 90-degree steering can run in both high and low speeds, enable electric lift work in small space.



Technical parameters:



Self-propelled scissor lift with battery GTJZ06
- Dimensions:
Max. Platform Height 6m
Max. Working Height 8m
Length-stowed 2.48m
Width-stowed 0.81 m
Min. Platform height 1.25m
Height ( guardrail folded ) 1.75m
Height ( guardrail stand) 2.21m
Platform Size 2.27 m * 0.81m
Length of extension platform 0.9m
Ground Clearance 0.1m
Wheelbase 1.87m
- Productivity:
Load Capacity 380kgs
Load capacity on extension platform 113kgs
Raise/ Lower speed 60/100 sec
Drive Speed (Stowed) 0 - 3.2km/h
Drive Speed (Raised) 0 - 0.8km/h
Turning radius-inside 0
Turning radius-outside 2.1m
Grade-ability 25%
Drives Dual front wheel
Brakes Dual rear wheel
Tire size (solid non-marking) 0.381 * 0.127m
- Power:
Batteries 24V DC (4 x 6V 210Ah batteries)
Motor power 3KW
Recharger 24v/25A
- Package & Price:
Package size: 2.7m x 1m x 1.95m
Total weight 1850kg
Certificate: CE / ISO















































































































Products pics:



6m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work 06m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work 16m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work 26m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work 3



Advantage:



1. Load weight: 300kg - 500kg

2. lift height: 4m 6m 8m 10m 12m 14m

3. Self moving, without outriggers.

4. One person can control the telescopic aerial work platform up down stop and move

5. Automatic pothole protection system

6. Slide-out battery trays
7. All motion alarm
8. Roll-out extension platform

9. Grooves on underframe for easy transportation
10. LED battery condition indicator
11. Fault diagnostic system
12. Tilt level sensor
13. Manual platform lowering valve for emergency
14. Solid non-marking tires



Product Parameters



Models
GTJZ-6
GTJZ-6A
GTJZ-8
GTJZ-8
GTJZ-10
GTJZ-12
GTJZ-14
Max. Working Height
7.8m
7.8m
9.8m
9.8m
11.8m
13.8m
15.8m
Max. Platform Height
5.8m
5.8m
7.8m
7.8m
9.8m
11.8m
13.8m
Platform Size
1.67×0.74×1.1m
2.3×1.15×1.1m
2.3×0.81×1.1m
2.3×1.15×1.1m
2.3×1.15×1.1m
2.3×1.15×1.1m
2.64×1.13×1.1m
Length-stowed
1.9m
2.45m
2.45m
2.475m
2.475m
2.475m
2.87m
Width-stowed
0.76m
1.18m
0.85m
1.18m
1.18m
1.18m
1.37m
Height-stowed
2.18m
2.24m
2.36m
2.36m
2.48m
2.60m
2.87m
Length/Load of Extended Platform
0.9m/113kg
0.9m/113kg
0.9m/113kg
0.9m/113kg
0.9m/113kg
0.9m/113kg
0.9m/113kg
Weight
1500kg
2000kg
2150kg
2100kg
2750kg
2950kg
3900kg
Max. Lift capacity
230kg
320kg
230kg
320kg
320kg
320kg
230kg
Drive speed-stowed
3.5km/h
3.5km/h
3.5km/h
3.5km/h
3.5km/h
3.5km/h
3.5km/h
Drive speed-raised
0.8km/h
0.8km/h
0.8km/h
0.8km/h
0.8km/h
0.8km/h
0.8km/h
Battery
24V/200Ah
24V/200Ah
24V/200Ah
24V/200Ah
24V/200Ah
24V/200Ah
24V/270Ah
Charger
24V/30A
24V/30A
24V/30A
24V/30A
24V/30A
24V/30A
24V/30



Certificates:



6m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work 46m 8m 12m 14m Hydraulic Mobile Self Propelled Elevating Work Platforms for aerial work 5





Our services



1) We can design the self-propelled scissor lift as per your requirement.
2) The scissor lift will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) Engineers are available to your country if necessary.
