|Load Capacity:||3T + 3T||Lift Height:||3M (as Request)|
|Platform Size:||5.6m X 2.7m||Motor:||From Italy Or Chinese Famous Brand|
|Application:||Double Parking Car Lift Portable Car Lift Equipment For 2 Cars Parking||Color:||Red, Grey, Yellow, Blue, Or As Your Optional|
|Lift System:||Hydraulic System||Power Supply:||220V/240V/380V/415V (as Request)|
|Material:||High Strength Manganese Steel||Safe Device:||Explosion-Proof Lock Valve|
stacker car parking system,
garage car elevator
3T+3T Double deck hydraulic scissor car garage lift for basement with CE SGS TUV:
- The Double Deck Scissor Car Lift can be used to lift car with different levels, suitable for car moving
between stairs, from basement to first floor, to second floor, or to third floor.
- Operation is easy. There are 2 sets control system installed on the scissor hydraulic auto car lift ,
1 control box below, and 1 hand controller on safety rail that can be operated on work platform.
The frequent models we supplied for our clients:
|MODEL||LOAD CAPACITY||PLATFORM SIZE||LIFT HEIGHT||PIT DEPTH||POWER|
|SJG2.5-3||2.5T||5.2m x 2.6m||3m||750mm||220V, 240V, 380V or 400V|
|SJG2-6.5||2T||5.2m x 2.8m||6.5m||800mm||220V, 240V, 380V or 400V|
|SJG2.5-3.5||2.5T||5.2m x 2.6m||3.5m||800mm||220V, 240V, 380V or 400V|
|SJG2.5-5||2.5T||5.6m x 3m||5m||800mm||220V, 240V, 380V or 400V|
|SJG3-2.5||3T||5m x 2.3m||2.5m||750mm||220V, 240V, 380V or 400V|
|SJG3-3||3T||5.2m x 2.6m||3m||800mm||220V, 240V, 380V or 400V|
|SJG3-3.5||3T||5.6m x 2.7m||3.5m||800mm||220V, 240V, 380V or 400V|
|SJG5-10||5T||4.5m x 2.5m||10m||1150mm||220V, 240V, 380V or 400V|
|SJG8-2.5||8T||6.5m x 4.5m||2.5m||850mm||220V, 240V, 380V or 400V|
|SJG12-3||12T||5.5m x 2.8m||3m||950mm||220V, 240V, 380V or 400V|
|SJG15-4.5||15T||8m x 2.2m||4.5m||1150mm||220V, 240V, 380V or 400V|
|SJG20-5||20T||6m x 3m||5m||1200mm||220V, 240V, 380V or 400V|
|The Double Deck Scissor Car Lift can be customized as your detailed size.|
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The safety rails to guarantee safety of the cars above the platform.
3) The limit switch system helps Double Scissor Lift Table to stop at accurate position.
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the Double Scissor Lift Table are passed 1.2 times loading test before leaving factory.
The Spare Parts:
Drive Motor,Hydraulic system: 380V/5.5kw
High Precision Hydraulic Cylinder: 110*4sets;
Scissor material: 200mm*100mm*10mm high strength Manganese Steel.Controller: 1 control box below, three buttons up down and stop, Very convenient and
simple; 1 control panel above platform
Platform Material: 120mm*60mm rectangular tube +6mm checkered iron
Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
1) We can design the Double Scissor Lift Table as per your requirement.
2) The most suitable Double Scissor Lift Table will be recommended to you once we got your
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) We could reply you in 2 hours after received your any questions even on weekend and
Engineers are available to your country if necessary.
