|Lifting Capacity:||3000kgs||Lifting Height:||3000 - 10000mm|
|Power:||220v, 240v, 380v, 400v Or Other||Certification:||CE|
|Warranty:||24 Months||Lift System:||Hydraulic System|
|Application:||Auto Car Parking Equipment||Install:||Underground|
lifting platforms equipment,
Mobile Aerial Work Platform
- The car parking equipment can be used to lift car with different levels, suitable for car moving between stairs, from basement to first floor, to second floor, or to third floor.
- Operation is easy. There are 2 sets control system installed on the car parking equipment, 1 control box below, and 1 hand controller on safety rail that can be operated on work platform.
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The safety rails to guarantee safety of the cars above the platform.
3) The limit switch system helps car parking equipment to stop at accurate position.
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the car parking equipment are passed 1.2 times loading test before leaving factory.
1) Platform Material: rectangular tube +checkered iron
2) Scissor material: high strength Manganese Steel.
3) Hydraulic system: 220v,380v or as clients requests.
4) High Precision Hydraulic Cylinder.
5) Piston Rod: hard chromium plating surface.
6) High-pressure oil pump
7) Hydraulic oil: summer 46#, winter 32#
8) Controller: 1 control box below, 1 control panel above platform
|Model||load capacity||Platform size||Lift height||Pit depth||Power|
|SJG2.5-3||2.5T||5.2m×2.6m||3m||750mm||220v, 240v,380v or 400v|
|SJG2-6.5||2T||5.2m×2.8m||6.5m||800mm||220v, 240v,380v or 400v|
|SJG2.5-3.5||2.5T||5.2m×2.6m||3.5m||800mm||220v, 240v,380v or 400v|
|SJG2.5-5||2.5T||5.6m×3m||5m||800mm||220v, 240v,380v or 400v|
|SJG3-2.5||3T||5m×2.3m||2.5m||750mm||220v, 240v,380v or 400v|
|SJG3-3||3T||5.2m×2.6m||3m||800mm||220v, 240v,380v or 400v|
|SJG3-3.5||3T||5.6m×2.7m||3.5m||800mm||220v, 240v,380v or 400v|
|SJG5-10||5T||4.5m×2.5m||10m||1150mm||220v, 240v,380v or 400v|
|SJG8-2.5||8T||6.5m×4.5m||2.5m||850mm||220v, 240v,380v or 400v|
|SJG12-3||12T||5.5m×2.8m||3m||950mm||220v, 240v,380v or 400v|
|SJG15-4.5||15T||8m×2.2m||4.5m||1150mm||220v, 240v,380v or 400v|
|SJG20-5||20T||6m×3m||5m||1200mm||220v, 240v,380v or 400v|
1) We can design the customerized car parking equipment as per your requirement.
2) The car parking equipment will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) Engineers are available to your country if necessary.
