Name: 3T 3m Heavy Duty Hydraulic Scissor Car Lift , Automotive Scissor Lift
Brand: SDLIFT Or OEM
SKU: SJG3-3
Price: 3980 USD
Availability: InStock
Rating: 4.8 (104 reviews)

Product Details

Place of Origin: China

Brand Name: SDLIFT Or OEM

Certification: CE ISO SGS

Model Number: SJG3-3

Payment & Shipping Terms

Minimum Order Quantity: 1 UNIT

Price: USD3980- USD9800 / UNIT

Packaging Details: Iron case or plywood case package

Delivery Time: 30 days

Payment Terms: T/T

Supply Ability: 1200units per year

Get Best Price

Product Details

Product Description

High Light:
                                                                                                                                                                                                                                                                                                                home garage car lift, automotive scissor lift


Application:	Heavy Duty Hydraulic Scissor Car Lift	Design:	Scissor Type Car Lift
Platform:	Anti Skid Steel Plate	Power:	220v,240v,380v Or Other
Safety Device:	Explosion Proof Lock Valve	Lift System:	Hydraulic System
Install:	Underground, Into A Pit	Color:	Optional

Application:	Heavy Duty Hydraulic Scissor Car Lift
Design:	Scissor Type Car Lift
Platform:	Anti Skid Steel Plate
Power:	220v,240v,380v Or Other
Safety Device:	Explosion Proof Lock Valve
Lift System:	Hydraulic System
Install:	Underground, Into A Pit
Color:	Optional

3T 3m Heavy Duty Hydraulic Scissor Car Lift , Automotive Scissor Lift

Approved Heavy Duty Hydraulic Scissor Car Lift

Application:

- The hydraulic scissor car lift can be used to lift car with different levels, suitable for car moving between stairs, from basement to first floor, to second floor, or to third floor.

- Operation is easy. There are 2 sets control system installed on the hydraulic scissor car lift , 1 control box below, and 1 hand controller that can be operated on work platform.

The frequent models we supplied for our clients:

MODEL	LOAD CAPACITY	PLATFORM SIZE	LIFT HEIGHT	PIT DEPTH	POWER
SJG2.5-3	2.5T	5.2m x 2.6m	3m	750mm	220V, 240V, 380V or 400V
SJG2-6.5	2T	5.2m x 2.8m	6.5m	800mm	220V, 240V, 380V or 400V
SJG2.5-3.5	2.5T	5.2m x 2.6m	3.5m	800mm	220V, 240V, 380V or 400V
SJG2.5-5	2.5T	5.6m x 3m	5m	800mm	220V, 240V, 380V or 400V
SJG3-2.5	3T	5m x 2.3m	2.5m	750mm	220V, 240V, 380V or 400V
SJG3-3	3T	5.2m x 2.6m	3m	800mm	220V, 240V, 380V or 400V
SJG3-3.5	3T	5.6m x 2.7m	3.5m	800mm	220V, 240V, 380V or 400V
SJG5-10	5T	4.5m x 2.5m	10m	1150mm	220V, 240V, 380V or 400V
SJG8-2.5	8T	6.5m x 4.5m	2.5m	850mm	220V, 240V, 380V or 400V
SJG12-3	12T	5.5m x 2.8m	3m	950mm	220V, 240V, 380V or 400V
SJG15-4.5	15T	8m x 2.2m	4.5m	1150mm	220V, 240V, 380V or 400V
SJG20-5	20T	6m x 3m	5m	1200mm	220V, 240V, 380V or 400V
The hydraulic scissor car lift can be customized acar lifts your detailed size.

Parts showing:

CE Approved Car Lift Outdoor / Portable Hydraulic Scissor Car Lift

Configuration:

1) Platform Material: rectangular tube +checkered iron

2) Scissor material: high strength Manganese Steel.

3) Hydraulic system: 220v,380v or as clients requests.

4) High Precision Hydraulic Cylinder.

5) Piston Rod: hard chromium plating surface.

6) High-pressure oil pump

7) Hydraulic oil: summer 46#, winter 32#

8) Controller: 1 control box below, 1 control panel above platform

CE,TUV,SGS certificate :

CE Approved Car Lift Outdoor / Portable Hydraulic Scissor Car Lift

Safety:

1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.

2) The safety rails to guarantee safety of the cars above the platform.

3) The limit switch system helps hydraulic scissor car lift to stop at accurate position.

4) Electricity leakage protection device is equipped on, all electric components are CE certified.

5) All the hydraulic scissor car lift are passed 1.2 times loading test before leaving factory.

CE Approved Car Lift Outdoor / Portable Hydraulic Scissor Car Lift

Our services:

1) We can design the customerized hydraulic scissor car lift as per your requirement.

2) The hydraulic scissor car lift will be recommended to you once we got your requirement.

3) Shipment can be arranged from our port to your destination port.

4) Operation video can be sent to you if needed.

5) User-friendly English manual for machine installation using and maintenance.

6) 2 year warranty for whole machine without man-made faults.

7) We will send you parts for free if there are any non-human factors faults during warranty time.

8) Supply 24-hours technical assistance by email, telephone or other communication online.

9 Engineers are available to your country if necessary.

Contact:

Joyce Zhang
Tel: 86-531-85882730 Fax: 86-531-62321282
Mobile / whatsapp: 86-13046001082
