CE Approved 3m Height Portable Hydraulic Scissor Car Lift For Garage

Product Details

Place of Origin: China

Brand Name: DLIFT

Certification: CE, ISO

Model Number: SJG3-3

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: USD5800-12800/unit FOB Qingdao China

Packaging Details: iron case or fumigation wooden box or according to client' requirement

Delivery Time: 30 days after deposit

Payment Terms: T/T

Supply Ability: 1200 units/ per year

Get Best Price
Highlight:

3m Portable Hydraulic Scissor Car Lift

,

CE Approved Hydraulic Scissor Car Lift

,

Hydraulic Scissor Car Lift 3000kg Load

Table Size:
5400*2700mm
Power:
380v/50hz/3ph/4.0kw
Lift Drive / Actuation:
Hydraulic, Electric Motor
Warranty:
24 Months
Lift Mechanism:
Scissor Lift
Work Platform:
Anti-skid Steel Plate
Lift Height:
3000mm
Load Weight:
3000kgs
Table Size:
5400*2700mm
Power:
380v/50hz/3ph/4.0kw
Lift Drive / Actuation:
Hydraulic, Electric Motor
Warranty:
24 Months
Lift Mechanism:
Scissor Lift
Work Platform:
Anti-skid Steel Plate
Lift Height:
3000mm
Load Weight:
3000kgs
CE Approved 3m Height Portable Hydraulic Scissor Car Lift For Garage

CE Approved 3m lift height portable hydraulic scissor car lift elevator for garage



Description:



Stationary scissor car lift platform is a widely used car lift equipment. It's scissor structure, makes the lifting platform stability, big platform size and high bearing capacity. It makes a lot work more efficient and more security. It parks your car in the upstairs more efficient and security.



Advantages:



Hydraulic lifting system, the far-end control and multi-control points at the different floors could be realized hierarchical control. Stop anywhere at the pre-concerted and accurate location point. It can work under any condition, great load capacity, safe and reliable. There are sensitive overload protection devices locking device for falling protection.



Product parameters:



1) load capacity : 3000kgs
2) platform size : 5.4m x 2.7m
3) travel height : 3m
4) structure : high-strength Manganese steel
5) power : 380v/3ph/50hz/4.0kw

6) Installation : underground , into a pit



Safety:



1) The work platform equipped with anti-skid plate to prevent slipping for safe.

2) The work table can be equipped guardrails to guarante safety of the car.

3) The car lift has hydraulic overload protective organization to ensure that equipment will not lift when the load beyond its rated load capacity.

4) The car lift equipped single control solenoid valves to prevent the platform dropping if power failure. You can open the manual dropped valve to lower the platform to the home position.



Factory pictures:



CE Approved 3m Height Portable Hydraulic Scissor Car Lift For Garage 0

CE Approved 3m Height Portable Hydraulic Scissor Car Lift For Garage 1

CE Approved 3m Height Portable Hydraulic Scissor Car Lift For Garage 2

CE Approved 3m Height Portable Hydraulic Scissor Car Lift For Garage 3



The models we supplied for clients:



MODEL LOAD CAPACITY PLATFORM SIZE LIFT HEIGHT PIT DEPTH POWER
SJG2.5-3 2.5T 5.2m x 2.6m 3m 750mm 220V, 240V, 380V or 400V
SJG2-6.5 2T 5.2m x 2.8m 6.5m 750mm 220V, 240V, 380V or 400V
SJG2.5-3.5 2.5T 5.2m x 2.6m 3.5m 800mm 220V, 240V, 380V or 400V
SJG2.5-5 2.5T 5.6m x 3m 5m 750mm 220V, 240V, 380V or 400V
SJG3-2.5 3T 5m x 2.3m 2.5m 750mm 220V, 240V, 380V or 400V
SJG3-3 3T 5.2m x 2.6m 3m 800mm 220V, 240V, 380V or 400V
SJG3-3.5 3T 5.6m x 2.7m 3.5m 800mm 220V, 240V, 380V or 400V
SJG5-10 5T 4.5m x 2.5m 10m 1150mm 220V, 240V, 380V or 400V
SJG8-2.5 8T 6.5m x 4.5m 2.5m 850mm 220V, 240V, 380V or 400V
SJG12-3 12T 5.5m x 2.8m 3m 950mm 220V, 240V, 380V or 400V
SJG15-4.5 15T 8m x 2.2m 4.5m 1050mm 220V, 240V, 380V or 400V
SJG20-5 20T 6m x 3m 5m 950mm 220V, 240V, 380V or 400V



The Hydraulic Scissor Car Lift can be customized as your detailed size.





The customers visiting:



CE Approved 3m Height Portable Hydraulic Scissor Car Lift For Garage 4



The Certificates:



CE Approved 3m Height Portable Hydraulic Scissor Car Lift For Garage 5



Our services:



1) The Hydraulic Scissor Car Lift can be done as per your detailed parameter

2) Shipment can be arranged from our port to your destination port.

3) Operation video can be sent to you if needed.

4) English manual for car lift installation , using and maintenance.

5) 2 years warranty for whole machine without man-made faults.
6) We will send you parts for free with non-human factor faults during warranty time.
7) Supply 24-hours technical assistance by email, telephone or skype.
8) Engineers are available to your country if necessary.
