Product Details:
|
| Load Capacity: | 2500kgs / 2500kgs | Lift Height: | 3m |
|---|---|---|---|
| Control: | Control Box, Control Panel, 2 Remotes | Platform Size: | 5400mm X 2600mm |
| Lift System: | Hydraulic Motor Pump System | Lift Speed: | 3m - 4m |
| High Light: | 5t portable car hoists,3m portable car hoists,home garage mobile car lift |
||
mobile car lift equipment portable car hoists for home garage with CE
Parameters:
1) Load capacity: 2500kgs (lower platform)
2500kgs (upper platform)
2) Platform size: 5.4m x 2.6m (lower platform)
5.4m x 2.6m (upper platform)
3) Lift height: 3m
4) Height between platforms: 3m
5) Power: 380v/50hz/3ph/5.5kw
6) Control system: 1 control box, 1 control panel, 2 remotes
7) Control buttons: up, down, stop, emergency
8) Safety device: explosion-proof lock valve
9) Standard: CE, ISO9001
Application:
The portable car hoist can be used to lift car with different levels, suitable for car moving between stairs, from basement to first floor, to second floor.
Operation is easy. There are 3 sets control system installed on the portable car hoist , 1 control box below, and 1 hand controller, and 2 remotes that can be operated on work platform.
Products in our workshops:
Configuration:
1) Platform Material:120mm*60mm rectangular tube +6mm checkered iron
2) Scissor material: 200mm*100mm*15mm high strength Manganese Steel.
3) Hydraulic system: 380V/5.5Kw
4) High Precision Hydraulic Cylinder: 100*4sets
5) Piston Rod: 70*4 hard chromium plating surface.
6) High-pressure oil pump
7) Hydraulic oil: summer 46#, winter 32#
8) Controller: 1 control box below, 1 control panel above platform
Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs
2) The limit switch system helps portable car hoist to stop at accurate position
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the portable car hoist are passed 1.2 times loading test before leaving factory.
The models we supplied for clients:
|
MODEL |
LOAD CAPACITY |
PLATFORM SIZE |
LIFT HEIGHT |
PIT DEPTH |
POWER |
|
SJG2.5-3 |
2.5T |
5.2m x 2.6m |
3m |
600mm |
220V, 240V, 380V or 400V |
|
SJG2.5-3.5 |
2.5T |
5.2m x 2.6m |
3.5m |
700mm |
220V, 240V, 380V or 400V |
|
SJG2.5-5 |
2.5T |
5.6m x 3m |
5m |
750mm |
220V, 240V, 380V or 400V |
|
SJG3-2.5 |
3T |
5m x 2.3m |
2.5m |
700mm |
220V, 240V, 380V or 400V |
|
SJG3-3 |
3T |
5.2m x 2.6m |
3m |
750mm |
220V, 240V, 380V or 400V |
|
SJG3-3.5 |
3T |
5.6m x 2.7m |
3.5m |
800mm |
220V, 240V, 380V or 400V |
|
SJG8-2.5 |
8T |
6.5m x 4.5m |
2.5m |
750mm |
220V, 240V, 380V or 400V |
|
SJG12-3 |
12T |
5.5m x 2.8m |
3m |
850mm |
220V, 240V, 380V or 400V |
|
SJG15-4.5 |
15T |
8m x 2.2m |
4.5m |
950mm |
220V, 240V, 380V or 400V |
|
The car lift equipment portable car hoist for home garage can be customized as your detailed size. |
|||||
The workshops:
CE Certificate:
Our service:
1) We can design the portable car hoist as per your requirement.
2) The portable car hoist will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) Engineers are available to your country if necessary.
