    Wheelchair Hydraulic Platform Lift , Residential Vertical Wheelchair Lifts for Homes

    Product Details:

    Place of Origin: China
    Brand Name: SDLIFT
    Certification: CE, ISO9001, SGS
    Model Number: SJG0.25-3

    Payment & Shipping Terms:

    Minimum Order Quantity: 1unit
    Price: US1980- USD4800 / UNIT
    Packaging Details: Iron case or nude
    Delivery Time: 5-15 work days
    Supply Ability: 3600units per year
    Get Best Price Contact Now

    Detail Information

    Usage: Wheelchair Lift For Disabled People Home Use Small Elevator Warranty: 24 Months
    Rated Loading Capacity: 250kg Min. Lifting Height: 80mm
    Max. Lifting Height: 3000mm Table Size: 1200mm(L) * 1000mm(W)
    Control: Calling Box And Remote Controller Material: Stainless Steel Or Aluminum Alloy With Powder Coating
    Lift Drive: Hydraulic Lift Mechanism: Lift Chain
    OEM: Available
    High Light:

    Wheelchair Platform Lift

    ,

    Scissor Car Lift

    Product Description

    Wheelchair Hydraulic Platform Lift , Residential Vertical Wheelchair Lifts for Homes

    Wheelchair Lift For Disabled People Home Use Small Elevator with CE

    with 2 Years Warranty:

    Application:
    The Wheelchair Lift For Disabled People Home Use Small Elevator provides convenient, reliable and safe access between different levels, supporting a wide selection of application.
    It is divided into two types according to material, which Spray type and Stainless Steel type.
    Characterized by novel design, perfect stability and safety, nice appearance, low noise and so on, with 1.0 - 6.0m working range, 150-350kg carrying capacity. Ideal for indoor and outdoor application.


    Wheelchair Lift Sketch Map:
    Wheelchair Hydraulic Platform Lift ,  Residential Vertical Wheelchair Lifts for Homes  0
    Wheelchair Hydraulic Platform Lift ,  Residential Vertical Wheelchair Lifts for Homes  1

    Technical Parameters:


    Platform size

    1200mm(L)* 1000mm(W)

    Dimension

    1200mm(L)*1450mm(W)* Travel height +700-1100 mm(H)

    Max Platform Height

    1000mm to 6000mm

    Min Platform height

    60mm

    Configuration

    Open through or front and side entrances

    Speed

    60mm/s

    Load capacity

    250KG~350KG

    Control voltage

    24V/DC

    Power Output

    2.2KW

    Power Input

    220V/50HZ/25A (or customized for local power supply)

    Drive System

    Hydraulic  or screw

    Control Mode

    Inching Switch or Automatic

    Drive Control

    Self-resetting system

    Overload

    Protection Over current relay

    Material of Platform

    Plastic electrostatic spraying

    Painting

    Plastic electrostatic spraying

    Guard panel & drive cabinet
    (framework)

    Aluminum Alloy / 304 stainless steel


    Operation Panel

    Polished aluminum Alloy

    Safety Wane Working Range

    75°

    Working Condition

    Both indoors and outdoors

    Working temperature

    From -10°~60°C

    Installation


    Non-pit installation, directly fixed to concrete floor
    (the concrete floor below the platform shall not be
    lower than the ground)

    Control Device


    Calling box (installed on the wall nearby) and remote
    controller(Extra optional)

    Emergency Stop


    The lifting and lowering process can be stopped immediately
    by pressing the emergency button.

    Safety device

    Safety Interlock

    Lock the platform when it is out of control

    Safety Sensor

    The operation must be stopped immediately
    the safety edge meets obstacles during
    operation .

    Emergency lowering

    The platform can be lowered by opening
    hydraulic valve manually or rolling screw rod.

    Auto-flap

    Turn up after lifting


    Product pictures:

    Wheelchair Hydraulic Platform Lift ,  Residential Vertical Wheelchair Lifts for Homes  2
    Wheelchair Hydraulic Platform Lift ,  Residential Vertical Wheelchair Lifts for Homes  3

    The workshops:


    Our services:

    1) We can design the Wheelchair Lift For Disabled People Home Use Small Elevator as per your requirement.
    2) The most suitable Wheelchair Lift For Disabled People Home Use Small Elevator will be recommended to you once we get your requirement.
    3) Shipment can be arranged from our port to your destination port.
    4) Operation video can be sent to you if needed.
    5) User-friendly English manual for machine installation using and maintenance.
    6) 2 year warranty for whole machine without man-made faults.
    7) We will send you parts for free if there are any non-human factors faults during warranty time.
    8) Supply 24-hours technical assistance by email, telephone or other communication online.
    9)
    Engineers are available to your country if necessary.
