Product Details:
|
| Usage: | Hydraulic Vertical Platform Lift For The Disabled People Wheelchair Stairlift | Load Capacity: | 250kgs |
|---|---|---|---|
| Lift Height: | 3000mm | Material: | Aluminum Alloy |
| Installation: | On The Ground | Table Size: | 1200mm(L) * 1000mm(W) |
| Control: | Calling Box And Remote Controller | Lift Drive: | Hydraulic Cylinder |
| Lift Mechanism: | Lift Chain | OEM: | Available |
| High Light: | patient lifting hoists,disability lifting equipment |
||
Hydraulic Vertical Platform Lift for The Disabled People Wheelchair Stairlift
Accepts the customization for lifting height and platform size.
Stairlift adopts new material-aluminium Alloy, which made the lift to be light weight, more durable and easy installation. It can easily operation and wheelchair lift loading capacity is 250kg or other as clients requests.
|
Specification:
|
|||
|
Model
|
SJGL0.25-3
|
||
|
Load capacity
|
250kg
|
||
|
Max. Platform Height
|
3000mm
|
||
|
Platform size
|
1200mm(L)* 1000mm(W)
|
||
|
Dimension
|
1200mm(L)*1350mm(W)*3800mm(H)
|
||
|
Min Platform height
|
80mm
|
||
|
In and out
|
180°in and out
|
||
|
Self weight
|
750kg
|
||
|
Material
|
Stainless steel or aluminum alloy with Powder coating
|
||
|
Power Input
|
220V/50HZ/1PH/2.2KW
|
||
|
Convenient operation design:
|
|
||
|
Drive System
|
Hydraulic
|
||
|
Control Mode
|
Inching Switch
|
||
|
Drive Control
|
Self-resetting system
|
||
|
Calling device
|
Calling box (Located at ground and upstairs), remote controller (optional)
|
||
|
Column switch
|
Two column switches, one is on the ground floor, one on the first floor
|
||
|
Working temperature
|
From -10°~60°C
|
||
|
Overload
|
Protection over current relay
|
||
|
Automatic ramp
|
75°ramp Range
|
||
|
Working Condition
|
Both indoors and outdoors
|
||
|
Installation
|
Non-pit installation, directly fixed to concrete floor
|
||
|
Safety Device:
|
|
||
|
Safety Interlock:
|
Lock the platform when it is out of control
|
||
|
Emergency Stop
|
The lift can be stopped immediately in case of any emergency
|
||
|
Emergency Lowering
|
The platform can be lowered by manual down button in case of power failure
|
||
|
Safety Sensor
|
The lift will be stopped immediately if the safety edge meets obstacles when going down.
|
||
|
Auto-flap ramp
|
Turn up to max 75°and prevent the wheelchair outside
|
||
1) We can design the customized stairlift as per your requirement.
2) The stairlift will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
